How to Run Pipes Through Walls and Floors for DIY Plumbing Work
If you’re DIY-er operating pipes, we’ll guide you to guide your plumbing wall through the most challenging places.
The pipes that supply water to toilets, showers, faucets as well as other fixtures are often concealed behind walls or beneath floors. This arrangement requires careful planning to ensure proper installation. After you’ve created a plan for the new plumbing it’s crucial to develop an approach to connecting the pipes. If it’s a brand new construction or an addition that has the framing is visible it’s easy. However, when you’re renovating a kitchen, bathroom and kitchen you must be prepared to change the design once you’ve removed the flooring and walls.
Replacing surfaces that have been completed when the plumbing (especially wall patching) typically takes a few days. Repairing large wall patches (or even replacing the entire wall) requires a bit longer than a tiny patch, so be sure to leave enough space to work.
After you have removed the drain and vent lines, connecting the supply that are typically run along drain-waste vent (DWV) pipelines is fairly simple. Before beginning learn about the basics of carpentry, understand your home’s design and ensure you are aware of the best way to install pipes. It’s important to get your plans approved by your city’s building departments to ensure it is in compliance to plumbing regulations.
Instructions
How to Run Pipes Through Walls and Floors
Every home renovation, addition or new construction that requires plumbing will typically involve the use of pipes. Learn how to navigate the tricky places in walls and floors by following these steps.
1 . Assess and Remove the Wall
If you’re looking to build a new stack, check the framing. A toilet installation has to have a drain that is 3 inches that can be put in only if the wall is constructed of 2x6s or greater (2-inch pipe is able to be installed through a wall of 2×4). The wall must be removed all the way to the ceiling
2 . Prep for New Pipe
Make a hole, allowing space to accommodate the pipe. For a pipe of 3 inches make use of an electric drill and a reciprocating cut to cut a hole approximately 4 1/4 inches wide by 10 inches in both the lower plate of the room that you’re working in as well as on top of that room beneath. Cut off a 10-inch x two-foot piece of flooring.
Read More : What Are the Pros and Cons of a Pebble Shower Floor
3 . Assemble and Place Drainpipe
Install the fittings that are approved onto on top of the drainpipe. Be sure to ensure that they face in the right direction. The drainpipe should be larger than what is needed. You can cut it down to size in the future from below. Slide the pipe through the hole.
4 . Run the Vent
You may need to cut an opening in the wall either above or below the floor to direct the vent pipe upwards or it down. If you are in the attic, you may be able to connect the vent to join one already existing vent. If not, you can drill an opening in the ceiling in the attic and have an expert roofer install an attic roof jack to connect your vent pipe.
5 . Guide and Attach Pipes
The drainpipe is secured with straps. Make a smaller hole in the ceiling to accommodate to vent the pipe. For a 1 1/2-inch vent pipe that’s 2 1/2 inches, a hole is enough. Leap the vent pipe upwards through the hole, and then into the attic or room above, and then slip its lower part into the fitting near the floor.
The passage of drainpipes through joists calls for careful work. The holes must be in an exact horizontal line along the floor. Then, they should be able to ascend or descend, so that the pipe slopes 1/4 inch for each foot. (If the joists measure 16 inches across and the pipes cross them at an angle of right the holes must differ in height by 3/8 inches.)
Vent pipes can be at a level, but certain codes require an incline towards the drain that is used for main drainage. Drain lines should be sloped. For a precise slope draw a line of level across the studs and determine the slope by measuring down 1/4 inch per running foot. Be aware that codes may require fireproof caulk in walls.
Read More : A Step-by-Step Guide to Identification old Shower Valve
6 . How to Stabilize and Protect Pipes
If you can, always run pipes through the holes in the center of the framing member. To stop pipes from getting rattled and rattling, line the holes with felt or wood shims. Place a shim beneath the pipe and tap it until it is securely in place, but not too tight in order to allow expansion. If you require notches then make them as tiny as you can, since they make the framing member weaker. Metal plates to shield pipe from nail damage.
7 . Tips for Running Pipe Through a Floor
The passage of drainpipes through joists calls for careful work. The holes should follow an exact line across the floor. They must be able to ascend or descend so that the pipe is sloped 1/4 inch for each foot. (If the joists are 16 inches across and the pipes cross them at an angle of right and the holes are different in height by around 3/8 inches.)
8. Tips for Running Pipe Through a Wall
Vent pipes may run at a in a straight line, however certain codes require an incline towards the primary drain. Drain lines should be sloped. To determine a slope precisely make sure you draw a level line on the studs , and then take a measurement of 1/4-inch for each running foot. Be aware that codes may require fireproof caulk in walls.
